JT&T Products

HVAC/R Wiring Kit A Large assortment of terminals, twist on connectors, compressor leads and high temp terminals for HVAC/R applications. Sturdy plastic organizer box and product map included. See Specs tab for complete listing of included items. ? WARNING: Cancer and reproductive harm - www.p65warnings.ca.gov

HVAC/R Master Wiring Kit A Large assortment of terminals, twist on connectors, compressor leads and high temp terminals for HVAC/R applications. Sturdy plastic organizer box . Includes heat shrink terminals! See Specifications Tab for complete listing of included items. ? WARNING: Cancer and reproductive harm - www.p65warnings.ca.gov

HVAC/R Screw Kits  6964F - Needle Point, Hex/slot washer head.  Contains: #10x1" - 25, #10x3/4" - 25, #8x3/4" - 50, #8x1/2" - 50, #7x1/2" - 50, #6x3/8" - 50 6965F - Self Drilling, Hex washer head Contains: #10x1" - 50, #10x3/4" - 50, #8x3/4" - 50, #8 x1/2" - 50 ? WARNING: Cancer and reproductive harm - www.p65warnings.ca.gov

Vinyl Vacuum Cap Assortment - Black, 1/8" - 1/2", 30 pcs

Vinyl Vacuum Cap Assortment - Rainbow, 1/8" - 3/8", 35 pcs

Vinyl Vacuum Cap Assortment - Rainbow, 1/8" - 3/8", 50 pcs

Hole size is approx 7/8" x 1 1/8"JT&T offers a wide range of products including: sockets, pigtails, toggles & rocker switches.

Switch and panel combo. SPST / Single Position, Single Throw illuminated red rocker switch on panel 2651E. Incandescent illumination, Rated at 16a at 12v,

Red LED Lit Rocker Switch - SPST / Single Position, Single Throw, fits 7/8" x 1-1/2" Slot, 4 x .250 tabs, rated at 16 amps   JT&T offers a wide range of products including: sockets, pigtails, toggles & rocker switches.

Hole size is approx 7/8" x 1 1/8", Incandescent illumination. JT&T offers a wide range of products including: sockets, pigtails, toggles & rocker switches.

Fits a 7/16" x 1-1/8" opening. Use with 2651E and 2953F panel mounts. SPST / Single Position, Single Throw. Two/three .250 tab terminals. Incandescent illumination.

Fits 13/16" Hole, outer edge of face is approx 15/16". SPST / Single Position, Single Throw, rated at 16a @ 12v.

Fits 13/16" Hole, outer edge of face is approx 15/16". SPST / Single Position, Single Throw, rated at 16a @ 12v.

Fits 1/2" Hole, SPST/ Single Position, Single Throw. Rated at 16a @ 12v. Fits 2650E and 2950E panel mounts. Three .250 tab terminals. Incandescent bulb

Fits 1/2" Hole, SPST/ Single Position, Single Throw. Rated at 16a @ 12v. Fits 2650E and 2950E panel mounts.Three .250 tab terminals.

Fits 1/2" round hole, Fits 2650E and 2950F Panel mounts. SPST / Single Position, Single Throw. Rated at 16a @ 12v. Three .250 tab terminals. Incandescent illumination.

Marine rated, sealed IP68 Waterproof, heavy-duty rocker switch - 20A @12VDC or 15A @24VDC, .250 tabs Acutators/lenses are removeable SPST On/Off, LED illuminated"Pin" in product name indicates the number of terminals on the back of the switch. Note however, the pin count is not the best way to determine if a switch is interchangeable with another.  Labels and panels available Hole size .83" x 1.46" (22x38mm)

Marine rated, sealed IP68 Waterproof, heavy-duty rocker switch - 20A @12VDC or 15A @24VDC, .250 tabs Acutators/lenses are removeable SPDT On/Off/On, LED illuminated. Off in middle position, can be clicked (and will stay) to 'on' in two directions. "Pin" in product name indicates the number of terminals on the back of the switch. Note however, the pin count is not the best way to determine if a switch is interchangeable with another. Labels and panels available Hole size .83" x 1.46"...

Marine rated, sealed IP68 Waterproof, heavy-duty rocker switch - 20A @12VDC or 15A @24VDC, .250 tabs Acutators/lenses are removeable SPST (On)/Off, LED illuminated. Rests in the 'off' position and is momentary on (pops back to off when released). "Pin" in product name indicates the number of terminals on the back of the switch. Note however, the pin count is not the best way to determine if a switch is interchangeable with another. Labels and panels available Hole size .83" x 1.46" (22x38mm) ...

Marine rated, sealed IP68 Waterproof, heavy-duty rocker switch - 20A @12VDC or 15A @24VDC, .250 tabs Acutators/lenses are removeable DPDT On/Off/On, LED illuminated. Off in the middle position, clicks (and stays) to an 'on' position in two directions. "Pin" in product name indicates the number of terminals on the back of the switch. Note however, the pin count is not the best way to determine if a switch is interchangeable with another. Labels and panels available Hole size .83" x 1.46"...

Marine rated, sealed IP68 Waterproof, heavy-duty rocker switch - 20A @12VDC or 15A @24VDC, .250 tabs Acutators/lenses are removeable DPST On/Off, LED illuminated"Pin" in product name indicates the number of terminals on the back of the switch. Note however, the pin count is not the best way to determine if a switch is interchangeable with another. Labels and panels available Hole size .83" x 1.46" (22x38mm)

Marine rated, sealed IP68 Waterproof, heavy-duty rocker switch - 20A @12VDC or 15A @24VDC, .250 tabs Acutators/lenses are removeable DPDT On/On"Pin" in product name indicates the number of terminals on the back of the switch. Note however, the pin count is not the best way to determine if a switch is interchangeable with another. Labels and panels available Hole size .83" x 1.46" (22x38mm)

Marine rated, sealed IP68 Waterproof, heavy-duty rocker switch - 20A @12VDC or 15A @24VDC, .250 tabs Acutators/lenses are removeable DPDT (On)/Off/(On), Momentary in both directions. Great for control of a motor that needs to 'out' then stop when released, or 'in' and stop when released."Pin" in product name indicates the number of terminals on the back of the switch. Note however, the pin count is not the best way to determine if a switch is interchangeable with another. Labels and panels...

JT&T's Vinyl Insulated Butt Connectors have been PVC injection molded with funnel entry for fast, easy wire insertion. Terminals have "V" groove serrations to provide maximum contact and tensile strength after crimping. JT&T's terminals are constructed from pure copper (Alloy 110), annealed & electro tin plated. Electro Tin plating provides exceptional corrosion resistance. Insulator sleeve is color-coded for wire size and identification. JT&T Products offers a full line of terminals made from...
